Product specifications
Characteristic | Value |
|---|---|
| Abrasion resistance | Premium |
| Bend radius min (inch) | 4.000 |
| Bend radius min (mm) | 101.600 |
| Brand | Synflex by Danfoss |
| Burst pressure (bar) | 827 |
| Burst pressure (psi) | 12000 |
| Color | Black |
| Compliances | SAE 100R18 |
| Conditional temp range | -65F to 150F fire resistant-65F to 150F for water based |
| Conductivity | Conductive |
| Cover material | Polyester (PET) |
| Inside diameter (inch) | 0.63 |
| Inside diameter (mm) | 16.00 |
| Lay line style | Ink jet |
| Outside diameter (inch) | 1.06 |
| Outside diameter (mm) | 26.92 |
| Package form | Box |
| Qualified hose fittings | 90390A90N |
| Reinforcement material | Fiberglass |
| Size | -10 |
| Tube wall thickness (inch) | 0.22 |
| Tube wall thickness (mm) | 5.46 |
| Working pressure max (bar) | 207 |
| Working pressure max (psi) | 3000 |
| Working temperature max (C) | 93 |
| Working temperature max (F) | 200.0 |
| Working temperature min (C) | -54 |
| Working temperature min (F) | -65.0 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 639789346292 |
