Product specifications
Characteristic | Value |
|---|---|
| Adjustment type | Screw |
| Brand | Danfoss |
| Cavity | C-8-3 |
| Factory set pressrue BAR | 52.000 |
| Factory set pressrue PSI | 750.000 |
| Flow rate GPM | 4.00 |
| Flow rate LPM | 15.000 |
| Fluid Compatibility | MIL-H-5606, SAE10, SAE20, etc |
| Function | Pressure Sequence Valve |
| Housing | No |
| Housing material | None |
| Installation type | Screw-in Cartridge |
| Leakage | 82 cc/min |
| Max working pressure BAR | 100.000 |
| Max working pressure PSI | 1500.000 |
| Min working pressure BAR | 28.000 |
| Min working pressure PSI | 400.000 |
| Model Code 1 | PSV4-8-V-S-0-15-XXX |
| Number of housing ports | 3 |
| Number of valve ports | 3 |
| Operating temperature | -40 C to 120 C (-40 to 248 F) |
| Operation | Pilot operated |
| Port Type | Cartridge Only |
| Pressure rating BAR | 350.000 |
| Product height in | 0.870 |
| Product height mm | 22.098 |
| Product length in | 4.420 |
| Product length mm | 112.268 |
| Product width in | 0.870 |
| Product width mm | 22.098 |
| Recommended filtration level | 18/16/13 |
| Seal Type | Viton |
| Special Features | None |
| Style | Spool |
| Valve torque into cavity | 34-41 Nm |
