Product specifications
Characteristic | Value |
|---|---|
| Brand | Danfoss |
| Cavity | C-10-4 |
| Coil termination | None |
| Diode | No |
| Flow rate LPM | 23.000 |
| Fluid compatibility | MIL-H-5606, SAE10, SAE20, etc |
| Function | Solenoid Valve |
| Housing | No |
| Housing material | Aluminum |
| Installation type | Screw-in Cartridge |
| Model Code 1 | SV2-10-4-0-00 |
| Model code | SV2-10-4-0-00 |
| Number of housing ports | 4 |
| Number of valve ports | 4 |
| Operating temperature | -40 C to 120 C (-40 to 248 F) |
| Operation | Electrically operated |
| Override type | None |
| Port type | Cartridge Only |
| Pressure rating BAR | 210.00 |
| Recommended filtration level | 18/16/13 |
| Seal type | Buna-N |
| Special features | None |
| Style | 4-Way 2-Position |
