Product specifications
Characteristic | Value |
|---|---|
| A Port flow LPM | 40.00 |
| A Port flow USGPM | 10.60 |
| Actuation type | Solenoid controlled |
| B Port flow LPM | 40.00 |
| B Port flow USGPM | 10.60 |
| Brand | Vickers by Danfoss |
| Build orientation | Solenoid at B port end |
| Build type | Standard |
| Coil voltage | 24 Volt DC |
| Command input | None |
| Communication protocol | None |
| Design series | 12 Series |
| Electrical Connection | Flying lead box |
| Feedback sensor | Yes |
| Fluid Compatibility | Antiwear hydraulic oils |
| Fluid cleanliness | 17/15/12 micron |
| Interface | ISO4401-03/NFPA D03/CETOP 3 |
| Manual override | Plain |
| Maximum pressure PSI | 5000 |
| Maximum pressure bar | 350 |
| Model code 1 | KSDG4V392L40MFH712EN48 |
| On board electronics | No |
| Performance | Servo |
| ProFX compatible | No |
| Reducer module | No |
| Reverse flow check | No |
| Seal Type | Viton |
| Special features | Special for BT Hydraulik |
| Spool Type | Closed centre (all ports) |
| Stage | Single stage |
| Symmetric flow | Yes |
| Tank port rating BAR | 210 |
| Tank port rating PSI | 3000 |
| Valve mount type | Subplate |
| Valve type | Proportional directional |
| Working temp max C | 70 |
| Working temp max F | 158 |
| Working temp min C | -20 |
| Working temp min F | -4 |
