Product specifications
Characteristic | Value | Description |
|---|---|---|
| Actuation Type | PRESSURE OPERATED | Pressure operated |
| Brand | VICKERS BY DANFOSS | Vickers by Danfoss |
| Design Series | 60 SERIES | 60 Series |
| Flow rate upto LPM | 340 | |
| Flow rate upto USGPM | 90.0 | |
| Fluid Cleanliness | 19/17/14 MICRON | 19/17/14 micron |
| Fluid compatibility | PETROLEUM OILS | Petroleum oils |
| High flow | YES | Yes |
| High vent spring | YES | Yes |
| Interface | 06 - 3/4" | 06 - 3/4" |
| Maximum pressure upto bar | 210 | |
| Maximum pressure upto psi | 3000 | |
| Model Code 1 | DGCH06FV60 | |
| Performance | STANDARD | Standard |
| Pressure adjustment range | 100-210 BAR (1500-3000 PSI) | 100-210 bar (1500-3000 psi) |
| Product height in | 6.690 | |
| Product height mm | 169.926 | |
| Product length in | 8.000 | |
| Product length mm | 203.200 | |
| Product width in | 2.750 | |
| Product width mm | 69.85 | |
| Seal type | BUNA-N | Buna-N |
| Special features | NONE | None |
| Valve Mount Type | SUBPLATE/MANIFOLD MOUNTED | Subplate/manifold mounted |
| Valve Type | PRESSURE RELIEF MODULE | Pressure relief module |
| Working temp max C | 70 | |
| Working temp max F | 158 | |
| Working temp min C | -20 | |
| Working temp min F | -4 |
