Aeroquip by Danfoss
11.031-42-32
Ftng (reus), R5 11.031 0008
This product has been discontinued.
The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.
Product specifications
Characteristic | Value |
|---|---|
| Angle (shape) | 90 Degree |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID | 2 in |
| Compatible hoses | 1503 |
| Construction style | Reusable |
| Drop dimension | 3.92 |
| End gender 1 | Female |
| End type 1 | Metric |
| End type 2 | Line/Hose/Tube |
| Feature | Fit for wide range of applicationsDurable and dependableCut assembly times and boost production |
| Finish/plating | Dura-Kote |
| Hex Size 1 | 2.36 in |
| Hex Size 2 | 2.17 in |
| Hose cut-off factor | 3.85 in |
| Hose dash size | -32 |
| Inside diameter | 1.69 in |
| Item type | Nipple Assembly |
| Product Height | 5.17 in |
| Product Length/Depth | 6.87 in |
| Product Type | Reusable Hose Fittings |
| Product Volume | 96.964 in³ |
| Product Weight | 3.54 lb |
| Product Width | 2.73 in |
| Product material | Carbon steel |
| Sub-brand | None |
| Thread Size 1 | M52X2 |
| Thread sealant | No |
| Trade Name | 11.031 Series |
