Aeroquip Performance by Danfoss
FCL4134
Ftng (perm), PERF SAE 37 90 Deg Fitting
This product has been discontinued.
The product is no longer available for purchase, but you can still find information about it, including service manuals, drawing etc.
Product specifications
Characteristic | Value |
---|---|
Angle (shape) | 90 Degree |
Brand | Aeroquip Performance by Danfoss |
Compatible hose ID | .625 in |
Construction style | Crimp |
Drop dimension | 1.12 |
End Size 1 | 7/8 IN |
End gender 1 | Female |
End type 1 | SAE 37 |
End type 2 | Line/Hose/Tube |
Feature | System engineered to extend hose assembly lifeHigh performance to increase uptime in critical operationsSuperior durability made to last |
Finish/plating | Black Anodized |
Hex Size 1 | 1 in |
Hose cut-off factor | 1.04 in |
Hose dash size | -10 |
Inside diameter | .47 in |
Item type | Fitting Assembly |
Product Height | 2.139 in |
Product Length/Depth | 2.257 in |
Product Type | Crimp Hose Fittings |
Product Volume | 5.016 in³ |
Product Width | 1.039 in |
Product material | Aluminum |
Sub-brand | None |
Thread Size 1 | 7/8-14 |
Thread sealant | No |
Trade Name | None |
UPC | 678146218797 |
