Product specifications
Characteristic | Value |
|---|---|
| Auxiliary mounting | SAE B Pad |
| CPRV setting | 220 psi [15 bar] |
| Charge pump | Charge pump included |
| Charge pump displacement | 1.28 cid [21.0 cc] |
| Charge pump special features | No CP SPL features |
| Control | HDC 4.5-20.0bar (65-290psi) |
| Control orifice upper servo S1 | No control orifice S1 |
| Control orifice upper servo S2 | No control orifice S2 |
| Control special features | NO CONTROL SPECIAL FEATURES |
| Control supply orifice | ORF - 1.32 [.052] Dia |
| Design Code | DESIGN CODE B |
| Design type | Series 1, Models 33-64 |
| Displacement | 4.594 cid (75.28 cc) |
| Flow rate GPM | 82.70 |
| Flow rate LPM | 313.2 |
| Identification | Standard |
| Input rotation | COUNTERCLOCKWISE (LEFTHAND) |
| Input shaft | 21T 16/32 pitch spline |
| Main ports | 1.00 code 62 no gauge ports |
| Maximum output speed | 4160 |
| Maximum temperature C | 82.20 |
| Maximum temperature F | 180.00 |
| Model Code 1 | ACA462321L0B00HDD000000B30D000 |
| Model Code 2 | 00B |
| Output torque lbf*in | 4386.9 |
| Output torque n*m | 495.7 |
| Paint | Painted primer blue (Standard) |
| Power limiter valve set port A | PL Port A, None |
| Power limiter valve set port B | PL Port B, None |
| Press override | No internal pressure override |
| Pressure override setting | IPOR setting - None |
| Product series | HST - Heavy duty variable pump |
| Second disp of dual element | No dual element |
| Special pump assembly features | No special features |
| Type | Variable displacement pump |
| Valve plate | Standard, V-Groove |
| Working pressure bar | 414 |
| Working pressure psi | 6000 |
