Product specifications
Characteristic | Value |
|---|---|
| Additional functions | No additional functions |
| Aux mount features (rear) | [2BA] SAE FLGS 82-2, MH |
| Auxiliary port size & location | .750-16 UNF-2B SAE- C1 C2, LSP |
| Brand | Danfoss |
| CODE TITLE | 2.48 cid [40.6 cc] rear tandem |
| CPRV setting & routing | 250-300 psi RTC |
| Charge pump | .84cid[13.8cc], 1.3125-12 UN2B |
| Control assembly | MDC, WBN, NLS |
| Control servo orifice S1 & S2 | No control supply orifice |
| Control supply orifice (P) | Dia 0.91 [.036] |
| Design code | D |
| Destroke valve | Not required |
| Drain port size & location | 1.0625-12, D1D2,RS LSP,drainD4 |
| Flow rate gpm | 38.6 |
| Flow rate lpm | 146.3 |
| Identification | Standard |
| Input shaft | 41T 48/96, 24.4 [.96] SHEXT |
| Input shaft rotation | left hand rotation (ccw) |
| Main ports size & location | 1.3125-12 UN-2B SAE port- RS |
| Maximum output speed | 3600 |
| Maximum temperature C | 107.00 |
| Maximum temperature F | 225.00 |
| Model Code | AAFLBAE23DS1TT0MA0C000AAF0D |
| Model Code 1 | AAFLBAE23DS1TT0MA0C000AAF0D |
| Mounting flange | 2-bolt-B |
| Note | For more info, contact Danfoss |
| Output shaft | 9T 16/32, 31.8 [1.25] SHEXT |
| Output torque NM | 223.0 |
| Output torque lbf-in2 | 1973.5 |
| Paint | Primer per spec 209-13A |
| Relief valve setting port A | 5000 psi [344.7 bar] |
| Relief valve setting port B | 5000 psi [344.7 bar] |
| Special control options | No special control options |
| Special features | GP 2X.5625-18 SAE ports |
| Working pressure bar | 344.7 |
| Working pressure psi | 5000 |
