Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 3.212 |
| A dimension MM | 81.600 |
| Angle shape | Straight |
| Brand | Danfoss |
| Compatible hose ID IN | 0.620 |
| Compatible hose ID MM | 15.875 |
| Compatible hoses | GH134 |
| Construction Style | Reusable |
| End size 1 | -12 |
| End type 1 | Tube-O female long pilot |
| End type 2 | Line/hose/tube |
| Finish plating | Dura-Kote |
| Hose cut off factor IN | 1.661 |
| Hose cut off factor MM | 42.200 |
| Hose size | -10 |
| Inside diameter IN | 0.374 |
| Inside diameter MM | 9.500 |
| Product height in | 2.244 |
| Product height mm | 56.997 |
| Product length in | 3.212 |
| Product length mm | 81.584 |
| Product material | Carbon steel |
| Product width in | 0.826 |
| Product width mm | 20.980 mm |
| Thread sealant | No |
| Working temperature max C | 125 |
| Working temperature max F | 257 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
