Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 1.800 |
| A dimension MM | 45.720 |
| Angle shape | Straight |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 0.500 |
| Compatible hose ID MM | 12.700 |
| Construction Style | Reusable |
| End size 1 | -10 |
| Hex size 1 IN | 1.125 |
| Hex size 1 MM | 28.575 |
| Hex size 2 IN | 0.000 |
| Hose size | -10 |
| Inside diameter IN | 0.870 |
| Inside diameter MM | 22.090 |
| Product height in | 1.220 |
| Product height mm | 30.988 |
| Product length in | 1.800 |
| Product length mm | 45.720 |
| Product material | Brass |
| Product width in | 1.220 |
| Product width mm | 30.988 |
| Series | 100R5 Reusable |
| Working temperature min F | -40 |
