Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 3.075 |
| A dimension MM | 78.105 |
| Angle shape | Straight |
| Backup hex size IN | 1.063 |
| Backup hex size MM | 27.000 |
| Brand | Danfoss |
| Compatible hose ID IN | 0.750 |
| Compatible hose ID MM | 19.050 |
| Compatible hoses | 1503 |
| Construction Style | Reusable |
| End connection hex size IN | 1.060 |
| End connection hex size MM | 26.924 |
| End size 1 | -12 |
| End size 2 | -8 |
| End type 1 | Male pipe (NPTF) |
| Hose cut off factor IN | 1.280 |
| Hose cut off factor MM | 32.512 |
| Hose size | -12 |
| Inside diameter IN | 0.610 |
| Inside diameter MM | 15.494 |
| Product material | Brass |
| Series | 100R5 Reusable |
| Thread size 1 | 3/4-14 NPTF |
