Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.630 |
| A dimension MM | 66.802 |
| Angle shape | 45 Degree |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 0.380 |
| Construction Style | Reusable |
| Drop dimension IN | 0.960 |
| Drop dimension MM | 24.38 |
| End size 1 | -6 |
| End Type 1 | Male 45 degree inverted flare |
| Finish plating | Zinc plating |
| Hex size 1 IN | 0.629 |
| Hex size 1 MM | 16.000 |
| Hex size 2 IN | 0.472 |
| Hex size 2 MM | 12.000 |
| Hose cut off factor IN | 1.940 |
| Hose cut off factor MM | 49.276 |
| Inside diameter IN | 0.2400 |
| Inside diameter MM | 6.0960 |
| Product height in | 1.579 |
| Product height mm | 40.130 |
| Product length in | 2.929 |
| Product length mm | 74.400 |
| Product material | Carbon steel |
| Product width in | 0.750 |
| Product width mm | 19.050 mm |
| Reusable socket hex MM | 19.000 |
| Thread sealant | No |
| Thread size 1 | 5/8-18 UNF |
| Working pressure max BAR | 275.00 |
| Working pressure max PSI | 4000.00 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 678146146120 |
