Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 4.114 |
| A dimension MM | 104.500 |
| Angle shape | 90 Degree |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 0.880 |
| Compatible hose ID MM | 25.400 |
| Compatible hoses | 1503 |
| Construction Style | Reusable |
| Drop dimension IN | 3.012 |
| Drop dimension MM | 76.50 |
| End size 1 | -16 |
| End type 1 | Female 37 degree swivel |
| Finish plating | Dura-Kote |
| Hex size 1 IN | 1.614 |
| Hex size 1 MM | 41.000 |
| Hex size 2 IN | 1.181 |
| Hex size 2 MM | 30.000 |
| Hose cut off factor IN | 2.953 |
| Hose cut off factor MM | 75.000 |
| Hose size | -16 |
| Inside diameter IN | 0.807 |
| Inside diameter MM | 20.500 |
| Product height in | 3.690 |
| Product height mm | 93.726 |
| Product length in | 4.920 |
| Product length mm | 124.968 |
| Product material | Carbon steel |
| Product width in | 1.860 |
| Product width mm | 47.244 mm |
| Thread sealant | No |
| Thread size 1 | 1 5/16-12 UN |
| Working pressure max BAR | 241 |
| Working pressure max PSI | 3500 |
| Working temperature max C | 121 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
