Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 8.830 |
| A dimension MM | 224.300 |
| Angle shape | 60 Degree |
| Compatible hose ID IN | 1.250 |
| Compatible hose ID MM | 31.750 |
| Compatible hoses | FC500 (Size dependent) |
| Compliances | SAE J1176 |
| Construction Style | Crimp |
| Drop dimension IN | 2.620 |
| Drop dimension MM | 66.60 |
| End Type 1 | Caterpillar flange |
| End size 1 | -24 |
| Finish plating | Dura-Kote |
| Hose cut off factor IN | 6.630 |
| Hose cut off factor MM | 168.300 |
| Hose size | -20 |
| Inside diameter IN | 0.9900 |
| Inside diameter MM | 25.2000 |
| Product height in | 5.200 |
| Product height mm | 132.080 |
| Product length in | 10.080 |
| Product length mm | 256.032 |
| Product material | Carbon steel |
| Product width in | 2.610 |
| Product width mm | 66.294 mm |
| Seal material | Ethylene propylene (EPDM) |
| Thread sealant | No |
| Working temperature max C | 127 |
| Working temperature max F | 260 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 678146156273 |
