Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 1.612 |
| A dimension MM | 40.970 |
| Angle shape | Straight |
| Construction Style | Crimp |
| End type 1 | Male pipe (NPTF) |
| Finish plating | Dura-Kote |
| Hex size 1 IN | 0.500 |
| Hex size 1 MM | 12.000 |
| Hex size 2 IN | 0.625 |
| Hex size 2 MM | 15.000 |
| Hose cut off factor IN | 1.051 |
| Hose cut off factor MM | 26.700 |
| Inside diameter IN | 0.078 |
| Inside diameter MM | 1.980 |
| Product height in | 0.500 |
| Product height mm | 12.700 |
| Product length in | 1.610 |
| Product length mm | 40.894 |
| Product material | Carbon steel |
| Product width in | 0.500 |
| Product width mm | 12.700 mm |
| Thread sealant | Yes |
| Thread size 1 | 3/8-24 UNF |
| Working temperature max C | 100 |
| Working temperature max F | 212 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 639789324542 |
