Product specifications
Characteristic | Value |
|---|---|
| Adjustment type | Knob |
| Brand | Danfoss |
| Cavity | C-16-2 |
| Flow rate LPM | 208.00 |
| Function | Needle Valve |
| Housing | No |
| Installation type | Screw-in Cartridge |
| Leakage | Standard |
| Maximum flow rate LPM | 208.00 |
| Minimum flow rate LPM | 5.00 |
| Model Code 1 | FCV6-16-K-0-NV |
| Number of housing ports | 2 |
| Number of valve ports | 2 |
| Operating temperature | -40 C to 120 C (-40 to 248 F) |
| Port type | Cartridge Only |
| Pressure rating BAR | 210.00 |
| Product height in | 1.500 |
| Product height mm | 38.100 |
| Product length in | 3.760 |
| Product length mm | 95.504 |
| Product width in | 1.500 |
| Product width mm | 38.100 |
| Seal type | Buna-N |
| Special features | None |
| Spool seal | No |
| Style | Flow Restrictor |
| Torque alu cavity | 108-122 Nm |
General specifications
Characteristic | Value |
|---|---|
| Proposition 65 | Cancer and Reproductive Harm |
