Product specifications
Characteristic | Value |
|---|---|
| A Port flow LPM | 24.00 |
| A Port flow USGPM | 6.30 |
| Actuation | Solenoid operated single stage |
| Actuation Type | Solenoid controlled |
| B Port flow LPM | 24.00 |
| B Port flow USGPM | 6.30 |
| Brand | Vickers by Danfoss |
| Build orientation | Solenoid at B port end |
| Coil Rating & Overrides | 24 VDC Amplifier supply, water-resistant overrides |
| Coil voltage | 24 Volt DC |
| Command input | +/-10V Command +/- 10V feedback |
| Command Signal | +/- 10V Voltage |
| Communication protocol | CANopen |
| Configuration level | Directional level - 1 |
| Design series | 01 Series |
| Digital Comm. Interface | CANOPEN |
| Electrical Connection | Electrical (PC7) 7 pin connector without plug |
| Electrical Connections | 7 -PIN connector without plug, no enable |
| EN Series | Omit for standard |
| External Sensor | NONE |
| Feedback sensor | Yes |
| Fluid cleanliness | 17/15/12 micron |
| Fluid Compatibility | Antiwear hydraulic oils and non alkyl-based Phosphate Esters |
| Interface | ISO4401-03/NFPA D03/CETOP 3/NG06 |
| ISO Interface | ISO 4401 size-03 |
| Manual override | None |
| Maximum pressure BAR | 350 |
| Maximum pressure PSI | 5000 |
| Model | Industrial proportional valves |
| Monitor Output | ±10V Voltage feedback signal |
| N: SPECIAL FEATURES | None |
| On board electronics | Yes |
| Performance | Servo |
| Pilot Supply & Drain Option | None_ |
| ProFX compatible | Yes |
| Reducer module | No |
| Reverse flow check | No |
| Seal Type | Viton |
| Software Version | Software version -001 |
| Spool Type | ISO4401-10/NFPA D10/CETOP 10/NG32 |
| Stage | Single stage |
| Symmetric flow | Yes |
| Tank port rating BAR | 250 |
| Tank port rating PSI | 3600 |
| Valve Mount Type | Subplate |
| Valve Type | AxisPro level 1 |
| Valve Type | Proportional valve with integrated amplifier and electronic feedback |
| Working temp max C | 70 |
| Working temp max F | 158 |
| Working temp min C | -40 |
| Working temp min F | -40 |
