Product specifications
Characteristic | Value | Description |
|---|---|---|
| Actuation Type | Pilot operated | |
| Brand | Vickers by Danfoss | |
| Coil Rating | 110 VAC 50Hz | |
| Design Series | 10 Series | |
| Electrical Connection | ISO 4400 (Din 43650) connector | |
| Ext pilot pressure | Internal | |
| Flow rate upto GPM | 42.0 | |
| Flow rate upto LPM | 160.0 | |
| Fluid Cleanliness | 19/17/14 micron | |
| Fluid compatibility | Petroleum oils | |
| Indicator Light | No | |
| Int pilot drain | Internal | |
| Interface | ISO4401-05 | |
| Manual override | Plain | |
| Model Code 1 | DG5V52C2TMUA610 | |
| Performance | High performance | |
| Power Consumption | 54 VA | |
| Pressure rating BAR | 315.00 | |
| Pressure rating PSI | 4500.00 | |
| Seal type | Buna-N | |
| Solenoid Energising ID | Standard as per ANSI B93 9 | |
| Special features | None | |
| Spool Control | Pilot choke adjustment | |
| Spool Position Monitor | No | |
| Spool Type | Spool 2 | |
| Spring Arrangement | Spring centred | |
| Stage | Two stage | |
| Surge Suppr Damper | No | |
| Tank port rating BAR | 160.0 | |
| Tank port rating PSI | 2300 | |
| Valve Mount Type | Subplate/manifold mounted | |
| Valve type | Directional control valve | |
| Working temp max C | 80 | |
| Working temp max F | 176 | |
| Working temp min C | -20 | |
| Working temp min F | -4 |
