Product specifications
Characteristic | Value | Description |
|---|---|---|
| Actuation Type | Pilot operated | |
| Brand | Vickers by Danfoss | |
| Coil Rating | 24 VDC | |
| Design Series | 79 Series | |
| Electrical Connection | ISO 4400 (Din 43650) connector | |
| Ext pilot pressure | Internal | |
| Flow rate upto GPM | 227.0 | |
| Flow rate upto LPM | 60.0 | |
| Fluid Cleanliness | 19/17/14 micron | |
| Fluid compatibility | Petroleum oils | |
| Indicator Light | No | |
| Int pilot drain | External | |
| Interface | ISO4401-07 | |
| Manual override | Plain | |
| Model Code 1 | DG5S4043CMUH779 | |
| Pressure rating BAR | 210.00 | |
| Pressure rating PSI | 3000.00 | |
| Seal type | Buna-N | |
| Solenoid Energising ID | Standard as per ANSI B93 9 | |
| Spool Type | Spool 3 | |
| Spring Arrangement | Spring centred | |
| Stage | Two stage | |
| Tank port rating BAR | 210.0 | |
| Tank port rating PSI | 3000 | |
| Valve Mount Type | Subplate/manifold mounted | |
| Valve Type | Directional control valve |
