Product specifications
Characteristic | Value | Description |
|---|---|---|
| Actuation type | Solenoid operated | |
| Adjustment range | 35-140 bar (500-2000 psi) | |
| Adjustment type | Screw with locknut | |
| Brand | Vickers by Danfoss | |
| Coil voltage | 110 VAC 50Hz/120 VAC 60Hz | |
| Design Series | 110 Series | |
| Electrical connection | Fly.lead term. block 1/2" NPT | |
| Flow rate LPM | 454 | |
| Flow rate USgpm | 120.0 | |
| Fluid cleanliness | 19/17/14 micron | |
| Fluid compatibility | Petroleum oils | |
| Hi-vent spring | Yes | |
| Indicator Light | Yes | |
| Manual override | Plain | |
| Maximum pressure BAR | 210 | |
| Maximum pressure PSI | 3000 | |
| Model Code 1 | CG5100ACVMFTWLB6P08110 | |
| Performance | Standard | |
| Seal material | Nitrile | |
| Size | Size 10 | |
| Special feature | NN | None |
| Spring Arrangement | Spring offset | |
| Stage | Two stage | |
| Tank pressure bar | 155 | |
| Tank pressure PSI | 2250 | |
| Valve mount type | Subplate/manifold mounted | |
| Valve type | Pilot operated relief valve | |
| Working temperature max C | 70 | |
| Working temperature max F | 158 | |
| Working temperature min C | -20 | |
| Working temperature min F | -4 |
