Slip-in Cartridge Valves Cover 02-311554 (RIGHT)

CVCS 25 HFV3 W B29 10, CVCS25HFV3WB2910

02-157811


Tools

Product specifications

Characteristic
Value
AdjustmentYes
Adjustment typeWrench with hex locknut
BrandVickers by Danfoss
Cover typeValvistor prop throttle
Design series10 Design
Flow rate LPM590
Flow rate USgpm155.0
Fluid cleanliness18/16/13 micron
Fluid compatibilityPetroleum Oils
Gauge port threadBSPF
Insert ratio1:1.5
Insert typeDirectional
InterfaceYes
LeakageStandard
Model Code 1CVCS25HFV3WB2910
Normal functionNormally open
Pilot port orientationISO
Pressure rating BAR350
Pressure rating PSI5000
Seal materialBuna-N
SizeNG 25
Special featureNone
Spool position sensorNo
Valve typeCartridge valve cover
ValvistorYes
Valvistor typeProportional Throttle Valve
Working temp max C70
Working temp max F158
Working temp min C-20
Working temp min F-4
