Product specifications
Characteristic | Value |
|---|---|
| Motor function | Standard |
| Shaft Seal | NBR - Standard |
| Dust seal | Standard |
| Sensor | None |
| Packaging | Single pack |
| Name Tag | Danfoss name tag |
| Brake Release Port Dimension | n/a |
| Brand | Danfoss |
| Check valve function | Yes |
| Design code | 01 |
| Drain Port Dimension | G 1/4 |
| Front bearing type | Tapered roller bearing |
| Geometric displacement [cm3/r [in3/r]] | 311.2 [18.99] |
| Hydraulic valve function | None |
| Main port dimension | G 3/4 |
| Main port style | Sideport - staggered |
| Main port thread type | BSP |
| Model Code | MC4310AD04AB0200000000000AB00A |
| Motor Series | XL4 Series |
| Motor size | 310 |
| Motor type | Standard |
| Mounting flange dimension [pilot dia x height, bolt circle dia, hole [mm [inch]]] | 125.0 x 9.2, 160.0, 14.3 [4.92 x 0.36, 6.30, 0.56] |
| Mounting flange type | 4 Bolt - Square |
| Orbital gearwheel set | Standard |
| Orbital gearwheel set type | Geroler |
| Paint information | Painted, Black |
| Painted | Yes |
| Rear bearing type | Tapered roller bearing |
| SHAFT TYPE | Straight |
| Seal Kit | Z331-32 |
| Shaft Key | Rectangular key, 8 x 12 x 70 mm |
| Shaft dimension | Dia. 40 mm, M12 x 1.75-6H thread in shaft end |
| Special Features Assembly | Standard |
| Special features hardware | Standard |
| Sub brand | Xcel |
| Valve system | Disc valve with valve drive |
