Product specifications
Characteristic | Value |
|---|---|
| Pump | Open loop pump |
| Displacement type | Variable |
| Series | X-series |
| Configuration | Single unit |
| Displacement | 130 ccm/rev |
| Basic Standard | Metric |
| Mounting Flange | ISO3019/2 160A2SW |
| Rotation direction | Clockwise |
| Max displacement set | Max disp adj screw |
| Thru drive options | None |
| Main port | Sae port metric bolts |
| Main port orientation | Radial (side ports) |
| Main drive shaft end | ISO Straight key |
| Drive shaft seal config | Single shaft seal |
| Seal material | FKM |
| Yoke position indicator | Visual indicator |
| Surface coating | Primer jet black RAL 9005 |
| Control type | Pressure compensator |
| Disp adj options | Not applicable |
| Electronic amplifier | No amplifier card / n/a |
| Yoke displacement zone | Single side center a |
| Additional functions | None / not applicable |
| Pressure control options | None (depends on control type) |
| Power control | Not applicable |
| Pilot oil filter | None |
| V-valve_pilot oil sup | No venting valve |
| Position monitoring | Not applicable |
| Electric motor type | Not applicable |
| Control voltage | Not applicable |
| Customer adjustment | None |
| Special feature | None |
| Design number | per data spec. in D. table 15 |
| Model Code | PVX-130-R-DF-0000-000-15HDY PI |
| Brand | Danfoss |
| IPM FRAME SIZE | PVX-130cc 15 design Pump |
| Model Code 1 | PVX-130-R-DF-0000-000-15HDY PI |
| Model Code 2 | 000A0000000000000000015 |
| Sub brand | Hydrokraft |
