Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.300 |
| A dimension MM | 58.420 |
| Angle shape | Straight |
| Compatible hose ID IN | 0.380 |
| Construction Style | Reusable |
| End size 1 | -6 |
| End type 1 | Male pipe (NPTF) |
| Finish plating | Zinc plating |
| Hex size 1 IN | 1.875 |
| Hex size 1 MM | 48.000 |
| Hose cut off factor IN | 1.430 |
| Hose cut off factor MM | 36.322 |
| Inside diameter IN | 0.3000 |
| Inside diameter MM | 7.6200 |
| Product height in | 1.010 |
| Product height mm | 25.654 |
| Product length in | 2.300 |
| Product length mm | 58.420 |
| Product material | Carbon steel |
| Product width in | 0.880 |
| Product width mm | 22.352 |
| Seal material | Nitrile (NBR) |
| Thread sealant | Yes |
| Thread size 1 | 3/8-18 NPTF |
| Working pressure max bar | 552.00 |
| Working pressure max psi | 8100.00 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 678146066022 |
