Product specifications
Characteristic | Value |
|---|---|
| Motor function | Standard |
| Port Type | Sta 7/8-14 |
| Shaft Seal | NBR - Standard |
| Dust seal | Standard |
| Sensor | None |
| Packaging | Bulk box |
| Name Tag | Danfoss name tag |
| Accessories | None |
| Brake Release Port Dimension | n/a |
| Brand | Danfoss |
| Case flow options | 7/16-20 shuttle valve |
| Check valve function | Yes |
| Customer identification | None |
| Design Code | 01 |
| Design code | First |
| Displacement | 324.6 cm3/r [19.81 in3/r] |
| Drain Port Dimension | 7/16 - 20 UNF-2B SAE O-Ring port |
| Front bearing type | Tapered roller bearing |
| Geometric displacement [cm3/r [in3/r]] | 324.6 [19.81] |
| Hydraulic valve function | Hot oil shuttle valve |
| Low pressure relief | None |
| Low pressure relief | None |
| Main port dimension | 7/8 - 14 UNF-2B SAE O-Ring port |
| Main port style | Sideport - staggered |
| Main port thread type | UN / UNF |
| Model Code | ADK20AB45AA0300000000F0A |
| Motor Series | 4000 Compact Series |
| Motor size | 325 |
| Motor type | Wheel |
| Mounting flange dimension [pilot dia x height, bolt circle dia, hole [mm [inch]]] | 108.0 x 6.4, 147.6, 13.6 [4.25 x 0.25, 5.81, 0.54] Rear: 127.0 x 3.3, 147.6, 13.6 [5.00 x 0.13, 5.81, 0.54] |
| Mounting flange type | 4 Bolt - Wheel |
| Mounting type | 4 w p108 b148 h14 rear127 |
| Orbital gearwheel set | Standard |
| Orbital gearwheel set type | Geroler |
| Output shaft type | Tap 32mm m10 s6x50mm |
| Paint information | n/a |
| Paint packaging | No paint, bulk box option |
| Painted | No |
| Product | Motor |
| Product View (Switch) | Global (Standard) |
| Rear bearing type | Tapered roller bearing |
| Series | 4000 compact series |
| Series | 4000 compact series |
| Shaft Key | Square key, 6 x 50 mm |
| Shaft dimension | Dia. 32 mm, 1:10 ISO R775, M10 x 1.50-6H thread in shaft end |
| Special Features Assembly | Standard |
| Special assembly instructions | None |
| Special features hardware | None |
| Sub brand | Char-Lynn |
| Valve options | None |
| Valve system | Disc valve with valve drive |
