Product specifications
Characteristic | Value |
|---|---|
| Motor function | Standard |
| MOUNTING TYPE | 4 m p83 b106 h14 pl3 |
| Port Type | Man 3x3/8-16 |
| Shaft Seal | NBR - Standard |
| Dust seal | Standard |
| Sensor | Speed and Direction, Hall effect, 2 x 30 pulses, 610 mm [24.0 inch], wire lenght, Packard weather pac shroud connector |
| Packaging | Bulk box |
| Name Tag | Danfoss name tag |
| Accessories | Wpc s+d 2x30p |
| Brake Release Port Dimension | n/a |
| Brand | Danfoss |
| CUSTOMER IDENTIFICATION | None |
| Case flow options | 7/16-20 |
| Check valve function | Yes |
| Design Code | 06 |
| Design code | Sixth |
| Displacement | 194.8 cm3/r [11.89 in3/r] |
| Drain Port Dimension | 7/16 - 20 UNF-2B SAE O-Ring port |
| Front bearing type | Tapered roller bearing |
| Geometric displacement [cm3/r [in3/r]] | 194.8 [11.89] |
| Geroler options | Standard |
| Hydraulic valve function | None |
| Low pressure relief | None |
| Low pressure relief | None |
| Main port dimension | Port A: 0.500 inch & Port B: 0.625 inch drilled hole, 3 x 3/8 - 16 UNC-2B block mounting threads |
| Main port style | Sideport - staggered |
| Main port thread type | Manifold |
| Model Code | M02119AJ03AB0100010AB0000AFAAF |
| Motor Series | 2000 Series |
| Motor size | 195 |
| Motor type | Standard |
| Mounting flange dimension [pilot dia x height, bolt circle dia, hole [mm [inch]]] | 82.6 x 2.8, 106.4, 13.6 [3.25 x 0.11, 4.19, 0.54] |
| Mounting flange type | 4 Bolt - Magneto |
| Mounting type | 4 m p83 b106 h14 pl3 |
| Orbital gearwheel set | Standard |
| Orbital gearwheel set type | Geroler |
| Output shaft type | Tap 1.25in s5/16x1in |
| Output shaft type | Tap 1.25in s5/16x1in |
| Paint information | Primer, Black, Low gloss |
| Paint packaging | Primer low gloss black bulk |
| Painted | Yes |
| Pressure flow option | None |
| Product | Motor |
| Product View (Switch) | Global (Standard) |
| Rear bearing type | Tapered roller bearing |
| Seal Kit | 61258-000 |
| Seal options | Standard |
| Seal options | Standard |
| Series | 2000 series |
| Series | 2000 series |
| Shaft Key | Square key, 5/16 x 1 inch |
| Shaft dimension | Dia. 1 1/4 inch, 1:8 SAE J501, 1 - 20 UNEF-2A thread in shaft end |
| Special Features Assembly | Standard |
| Special assembly instructions | None |
| Special features hardware | Standard |
| Sub brand | Char-Lynn |
| Valve system | Disc valve with valve drive |
