Product specifications
Characteristic | Value |
|---|---|
| Motor function | Standard |
| Shaft Seal | HNBR - High pressure |
| Dust seal | Standard |
| Sensor | None |
| Packaging | Single pack |
| Name Tag | Danfoss name tag |
| Brake Release Port Dimension | n/a |
| Brand | Danfoss |
| Check valve function | Yes |
| Drain Port Dimension | G 1/4 |
| Front bearing type | Tapered roller bearing |
| Geometric displacement [cm3/r [in3/r]] | 305.7 [18.65] |
| Hydraulic valve function | None |
| Main port dimension | G 1/2, 2 x M10 x 1.5-6H block mounting threads |
| Main port style | Sideport - staggered |
| Main port thread type | BSP |
| Model Code | MC2305AB16AS02000130000ABAAAAB |
| Motor Series | XL2 Series |
| Motor size | 305 |
| Motor type | Wheel |
| Mounting flange dimension [pilot dia x height, bolt circle dia, hole [mm [inch]]] | 108.0 x 6.3, 147.6, 13.6 [4.25 x 0.25, 5.81, 0.54] Rear: 127.0 x #, 147.6, 13.6 [5.00 x #, 5.81, 0.54] |
| Mounting flange type | 4 Bolt - Wheel |
| Orbital gearwheel set | Standard |
| Orbital gearwheel set type | Geroler |
| Paint information | Painted, Blue |
| Painted | Yes |
| Rear bearing type | Tapered roller bearing |
| Seal Kit | Z331-51 |
| Shaft Key | Rectangular key, 10 x 8 x 45 mm |
| Shaft dimension | Dia. 32 mm, M8 x 1.25-6H thread in shaft end |
| Shaft type | Straight |
| Special Features Assembly | Direction of rotation |
| Special features hardware | Standard |
| Sub brand | Xcel |
| Valve system | Disc valve with valve drive |
