Product specifications
Characteristic | Value |
|---|---|
| Motor function | Standard |
| Shaft Seal | NBR - Standard |
| Dust seal | Standard |
| Sensor | None |
| Packaging | Bulk box |
| Name Tag | Danfoss name tag |
| Brake Release Port Dimension | n/a |
| Brand | Danfoss |
| Check valve function | Yes |
| Design Code | 01 |
| Drain Port Dimension | 7/16 - 20 UNF-2B SAE O-Ring port |
| Front bearing type | Tapered roller bearing |
| Geometric displacement [cm3/r [in3/r]] | 252.8 [15.43] |
| Hydraulic valve function | None |
| Main port dimension | 7/8 - 14 UNF-2B SAE O-Ring port |
| Main port style | Sideport - staggered |
| Main port thread type | UN / UNF |
| Model Code | ADK15AG04AA0100000000F0A |
| Motor Series | 4000 Compact Series |
| Motor size | 255 |
| Motor type | Wheel |
| Mounting flange dimension [pilot dia x height, bolt circle dia, hole [mm [inch]]] | 91.9 x 4.3, 147.6, 14.4 [3.62 x 0.17, 5.81, 0.57] - Spec. Component |
| Mounting flange type | 4 Bolt - Wheel |
| Orbital gearwheel set | Standard |
| Orbital gearwheel set type | Geroler |
| Paint information | n/a |
| Painted | No |
| Rear bearing type | Tapered roller bearing |
| SHAFT TYPE | Splined |
| Shaft Key | n/a |
| Shaft dimension | Dia. 1 1/4 inch, 14T, 3/8 - 16 UNC-2B thread in shaft end |
| Special Features Assembly | Standard |
| Special features hardware | Spec. Component |
| Sub brand | Char-Lynn |
| Valve system | Disc valve with valve drive |
