Product specifications
Characteristic | Value |
|---|---|
| Motor function | Brake - Low release pressure |
| Shaft Seal | NBR - Low pressure |
| Dust seal | Standard |
| Sensor | None |
| Packaging | Single pack |
| Name Tag | Danfoss name tag |
| Brake Release Port Dimension | G 1/4 |
| Check valve function | No |
| Delete Model Code | Yes |
| Design code | 2 |
| Drain Port Dimension | G 1/4 |
| Front bearing type | Tapered roller bearing |
| Geometric displacement [cm3/r [in3/r]] | 201.4 [12.29] |
| Hydraulic valve function | None |
| Main port dimension | G 3/4, 2 x M10 block mounting threads |
| Main port style | Sideport - staggered |
| Main port thread type | BSP |
| Model Code | OMT-0200-F-BA-W50-AB-1D-J14-C-A-1B-0-A-NN-NNNNN-NN-NN-NN-SP-NNN |
| Motor Series | OMT Series |
| Motor size | 200 |
| Motor type | Motor - Brake |
| Mounting flange dimension [pilot dia x height, bolt circle dia, hole [mm [inch]]] | 172.0 x 7.0, 200.0, M12 [6.77 x 0.32, 7.87, M12] |
| Mounting flange type | 4 Bolt - Wheel |
| Orbital gearwheel set | Standard |
| Orbital gearwheel set type | Geroler |
| Paint information | n/a |
| Painted | No |
| Rear bearing type | Tapered roller bearing |
| SHAFT TYPE | Wheel hub |
| Seal Kit | 151B0152 |
| Shaft Key | n/a |
| Shaft dimension | Bolt Flange: 5 x M14 x 1.5 - BCD 140 mm [5.5 inch] |
| Special Features Assembly | Standard |
| Special features hardware | Standard |
| Valve system | Disc valve with valve drive |
General specifications
Characteristic | Value |
|---|---|
| Proposition 65 | Cancer and Reproductive Harm |
